Standards |
IEEE802.11b/g & 802.11n (1T1R mode) |
|
Operating Frequency |
USA (FCC): 2.412GHz ~ 2.462GHz (channel 1 – 11) ISM band |
|
Europe (CE): 2.412GHz ~ 2.472GHz (channel 1 – 13) ISM band |
|
|
Protocols |
802.11b: CCK, QPSK, BPSK, 802.11g/n: OFDM |
|
Antenna |
Inside Antenna |
|
Security |
WPA/WP2, 64/128/152-bit WEP, WPS |
|
Standards |
IEEE802.11b/g & 802.11n (1T1R mode) |
|
Operating Frequency |
USA (FCC): 2.412GHz ~ 2.462GHz (channel 1 – 11) ISM band |
|
Europe (CE): 2.412GHz ~ 2.472GHz (channel 1 – 13) ISM band |
|
|
Protocols |
802.11b: CCK, QPSK, BPSK, 802.11g/n: OFDM |
|
Antenna |
Inside Antenna |
|
Security |
WPA/WP2, 64/128/152-bit WEP, WPS |
|
Transmit Output Power (Typical) |
11b: 19±1.0dBm @ 11Mbps; 11g: 16±1dBm @ 54Mbps |
|
Transmit Output Power (Typical) |
802.11n: (HT20), 16+/-1dBm, 802.11n: (HT40), 16+/-1dBm, |
|
Receive Sensitivity (Typical) |
11b: -84dBm @ 11Mbps; 11g: -72dBm @ 54Mpbs. |
|
Receive Sensitivity (Typical) |
802.11n: (HT20), -68dBm@MSC7, (HT40),-65dBm@MSC7 |
|
Operating Voltage |
5.0VDC ± 5% |
|
Operating Current |
<160mA at 5.0V DC input. |
|
Bus Interface |
USB 2.0/USB1.1 |
|
Antenna Impedance |
50 ohm |
